HD FAB
TITAN HD Folding access bracket

Ischebeck TITAN Heavy Duty Folding Access Bracket (HD FAB) is a simple, easy to erect, use and dismantle climbing formwork / access platform that is a direct relation of the popular FAB access platform. TITAN HD FAB provides a shutter roll back system that can accommodate various shutter solutions from traditional soldiers and aluminium shutters to proprietary panel systems.

Lightweight and easy to install, TITAN HD FAB can be delivered pre-assembled and flat packed to site. With a 2.3m wide working deck and high level of edge protection, HD FAB is engineered to give total confidence in safety and security.

Advantages

25 in./654 mm (min) to 28.3 in./720 mm (max) access to the inside of shutter in the rolled back position
Maximum pour height 12.7 ft (3.875 m)
28.3 in. (720 mm) access to the inside of the shutter available when using NOE panels
Accommodates shutter heights up to 13 ft. (3.975 m) high (higher shutters possible subject to design)
Units up to 23.6 ft. (7.2 m) wide feasible depending on shutter height/length and wind conditions
Units are flat packed for easy transportation, erect, use and dismantle
Up to 3 units can be transported on a standard flat bed trailer
High edge protection on the main deck provides safety and confidence
Units are fixed to wall on previously mounted wall brackets – setting out is not as critical as with other systems
Trailing platforms can be added beneath the HD FAB for retrieving anchors, or for follow on trades as required
